CERAMIC FIBER BOARDS
Ceramic Fiber Boards for Thermal Resistance
PRODUCTS > CERAMIC FIBER BOARDS
WHAT ARE CERAMIC FIBER BOARDS?
Ceramic Fiber Boards are made from aluminum silicate which thrives in high-temperature settings that need more than insulation. These boards are better than ceramic fiber blankets when it comes to strength, supporting applications with steel-like durability needs.
Ceramic Fiber Boards offers low heat storage, great mechanical strength and workability as they can be cut, drilled, or sawed to taste. They are also highly adaptable. Because ceramic fiber boards allow for easy customization to versatile applications, they enjoy widespread use across industries facing the toughest heat challenges.
APPLICATIONS
Axim’s ceramic fiber boards are integral to a wide range of applications for their thermal resistance, including:
Industrial
Furnaces & Kilns
Provides exceptional insulation, maintaining temperature stability and efficiency in high-heat environments.
Aerospace
Used in construction and insulation of aerospace components.
Automotive
Employed in heat shields and exhaust insulation - enhancing vehicle safety and performance by maintaining thermal conditions.
Energy Sector
Contributes to thermal management systems - ensuring energy efficiency and safety.
Appliance Insulation
Offers effective heat containment and protection in ovens and boilers.
Acoustic Insulation
Sound absorption properties makes them suitable for environments where noise resistance is a consideration.
TECHNICAL SPECIFICATIONS
|
Feature
|
Specification
|
|---|---|
|
Material Composition
|
High-purity aluminum silicate
|
|
Density
|
280 - 320 kg/m³
|
|
Heat Resistance
|
Ranges from 2300°F (1260°C) to 2600°F (1427°C)
|
|
Classification Temperature
|
2300, 2480, 2552, 2600F
|
|
Thermal Conductivity
|
0.09 W/(m·K) at 800°C
|
|
Compressive Strength
|
≥ 0.5 MPa at 25% compression
|
|
Tensile Strength
|
≥ 0.3 MPa
|
|
Flexural Strength
|
≥ 1.0 MPa
|
|
Shrinkage (at max temp)
|
<3% after 24 hours
|
|
Sizes Available
|
600 x 900mm, 600 x 1000mm, 1000 x 1200mm; custom sizes upon request
|
|
Thickness Range
|
6mm to 50mm (0.24” to 2”)
|
|
Color
|
Typically white or off white
|
TYPES OF CERAMIC FIBER BOARDS
Axim Mica’s Ceramic Fiber Boards are tailored to meet various industrial requirements, offering variants that cater to specific needs:
- Standard Grade: Ideal for general insulation applications, these boards provide robust thermal resistance and durability up to 2300°F. They’re perfect for furnaces, kilns, and general thermal barriers.
- High-Density Grade: Engineered for environments demanding extra strength and lower thermal conductivity, these boards withstand temperatures up to 2480°F. Suitable for load-bearing applications where mechanical stress is a factor.
- High-Temperature Grade: Specifically designed for the highest heat conditions, these boards perform exceptionally well up to 2600°F. They’re the choice for advanced industrial furnaces and critical aerospace applications.
BENEFITS & ADVANTAGES OF USING CERAMIC FIBER BOARDS
Axim Mica Ceramic Fiber Boards offer a host of advantages that make them a superior choice for thermal insulation needs:
- Outstanding Thermal Resistance: Safely withstands extreme temperatures, suitable for applications up to 2600°F.
- Enhanced Mechanical Strength: Offers higher durability than ceramic fiber blankets and felts, ideal for demanding environments.
- Keep Heat Locked In: Exhibits low thermal conductivity, maximizing energy efficiency by reducing heat transfer.
- Lightweight & Easy to Install: Simplifies handling and installation, can be easily cut, drilled, or saw to fit custom shapes and spaces.
- All-Around Usability: Suitable for a wide range of industrial uses from furnaces and kilns to aerospace and automotive insulation.
- Stay Green: Made from eco-friendly materials, supporting safer, cleaner industrial operations.
- Long Service Life: Engineered for durability, reducing the need for frequent replacements and maintenance.
HOW CERAMIC FIBER BOARDS ARE MADE
Creating Ceramic Fiber Boards is a meticulous process that starts with high-quality aluminum silicate. This base material is engineered to form a dense, durable board through the following steps:
- Blending: Aluminum silicate fibers are carefully blended, ensuring uniform distribution for consistent quality throughout each board.
- Forming: The blended fibers are then formed into boards under high pressure, which compacts the material and gives it its distinctive strength and insulation properties.
- Curing: After forming, the boards undergo a curing process. This step enhances their mechanical strength and thermal resistance, preparing them for high-temperature applications.
- Cutting and Finishing: Finally, the cured boards are cut to standard sizes or custom dimensions as required, and any necessary finishing touches are applied to meet specific project needs.
ENGINEERING EXCELLENCE WITH AXIM MICA
Ready to move forward? Our engineering team collaborates with clients to develop optimal solutions for their specific applications, ensuring every component meets exact specifications and performance requirements.
FAQs
Ceramic fiber board is a strong, lightweight insulation material made from aluminum silicate. It offers excellent thermal resistance and is used in high-temperature applications for insulation and fire protection.
The cost of ceramic fiber can vary, but it offers valuable benefits for thermal insulation and fire resistance in industrial applications. Its durability and performance often justify the investment over time.
While ceramic fiber board has many resistive qualities, it is not inherently waterproof. It’s designed to withstand high temperatures and insulate rather than repel water.
Ceramic fiber board is made from high-quality, refractory aluminum silicate fibers. These fibers are bonded together to form a dense, durable board that excels in high-temperature applications.
Yes, ceramic fiber is fireproof. It’s designed to withstand extreme temperatures up to 2600°F (1427°C), making it an ideal material for fire protection and thermal insulation in various industrial settings.
